DC Current Source

Ideal constant current source

  • DC Current Source block

Libraries:
Simscape / Foundation Library / Electrical / Electrical Sources

Description

The DC Current Source block represents an ideal current source that is powerful enough to maintain specified current through it regardless of the voltage across the source.

You specify the output current by using the Constant current parameter, which can be positive or negative.

The positive direction of the current flow is indicated by the arrow.

Ports

Conserving

expand all

Electrical conserving port associated with the source positive terminal.

Electrical conserving port associated with the source negative terminal.

Parameters

expand all

Current through the source. You can specify positive or negative values.

Extended Capabilities

C/C++ Code Generation
Generate C and C++ code using Simulink® Coder™.

Version History

Introduced in R2007a
