jitterColorHSV
Randomly alter color of pixels
Description
adjusts the color of RGB image J
= jitterColorHSV(I
,Name=Value
)I
with a randomly selected value of hue,
saturation, brightness, and contrast from the HSV color space. Specify the range
of each type of adjustment using name-value arguments.
Examples
Randomly Adjust Image Color
Read and display an image.
I = imread("kobi.png");
imshow(I)
Randomly adjust the hue, saturation, brightness, and contrast of the image. To demonstrate the randomness of the adjustment, repeat the operation on the original image three times.
J1 = jitterColorHSV(I,Contrast=0.4,Hue=0.1,Saturation=0.2,Brightness=0.3); J2 = jitterColorHSV(I,Contrast=0.4,Hue=0.1,Saturation=0.2,Brightness=0.3); J3 = jitterColorHSV(I,Contrast=0.4,Hue=0.1,Saturation=0.2,Brightness=0.3);
Display the adjusted images in a montage.
montage({J1,J2,J3},Size=[1 3])
Input Arguments
I
— RGB image
m-by-n-by-3 numeric array
RGB image with original pixel values, specified as an m-by-n-by-3 numeric array.
Data Types: single
| double
| uint8
| uint16
Name-Value Arguments
Specify optional pairs of arguments as
Name1=Value1,...,NameN=ValueN
, where Name
is
the argument name and Value
is the corresponding value.
Name-value arguments must appear after other arguments, but the order of the
pairs does not matter.
Example: J = jitterColorHSV(I,Hue=0.1)
adds a random amount of hue
from the uniform distribution [-0.1, 0.1].
Before R2021a, use commas to separate each name and value, and enclose
Name
in quotes.
Example: J = jitterColorHSV(I,"Hue",0.1)
adds a random amount of hue
from the uniform distribution [-0.1, 0.1].
Hue
— Hue offset
0
(default) | numeric scalar | 2-element numeric vector
Hue offset, specified as one of the following values.
jitterColorHSV
converts input RGB image I
to the HSV color space before adding a random value to the hue channel of the image.
jitterColorHSV
circularly wraps the modified hue to the range
[0, 1] before converting the jittered HSV image back to the RGB color space.
Value | Meaning |
---|---|
Numeric scalar in the range [0, 1] | Add random amount of hue from the uniform distribution [-Hue
Hue] |
2-element numeric vector with elements in the range [-1, 1] | Add a random amount of hue from a continuous uniform distribution within the specified interval. The second element must be larger than or equal to the first element. |
Data Types: single
| double
Saturation
— Saturation offset
0
(default) | numeric scalar | 2-element numeric vector
Saturation offset, specified as one of the following values.
jitterColorHSV
converts input RGB image I
to the HSV color space before adding a random value to the saturation channel of the
image. jitterColorHSV
clips the modified saturation to the range
[0, 1] before converting the jittered HSV image back to the RGB color space.
Value | Meaning |
---|---|
Numeric scalar in the range [0, 1] | Add random amount of saturation from the uniform distribution
[-Saturation Saturation] |
2-element numeric vector with elements in the range [-1, 1] | Add a random amount of saturation from a continuous uniform distribution within the specified interval. The second element must be larger than or equal to the first element. |
Data Types: single
| double
Brightness
— Brightness offset
0
(default) | numeric scalar | 2-element numeric vector
Brightness offset, specified as one of the following values.
jitterColorHSV
converts input RGB image I
to the HSV color space before adding a random value to the brightness (value) channel
of the image. jitterColorHSV
clips the modified brightness to the
range [0, 1] before converting the jittered HSV image back to the RGB color
space.
Value | Meaning |
---|---|
Numeric scalar in the range [0, 1] | Add random amount of brightness from the uniform distribution
[-Brightness Brightness] |
2-element numeric vector with elements in the range [-1, 1] | Add a random amount of brightness from a continuous uniform distribution within the specified interval. The second element must be larger than or equal to the first element. |
Data Types: single
| double
Contrast
— Contrast scale factor
0
(default) | positive number | 2-element numeric vector
Contrast scale factor, specified as one of the following values.
jitterColorHSV
converts input RGB image I
to the HSV color space before scaling the brightness (value) channel of the image by a
random factor. jitterColorHSV
clips the modified brightness to
the range [0, 1] before converting the jittered HSV image back to the RGB color
space.
Value | Meaning |
---|---|
Positive number | Scale the brightness by a random factor from the uniform distribution
[1-Contrast 1+Contrast] |
2-element numeric vector of positive numbers | Scale the brightness by a random factor from the uniform distribution within the specified interval. The second element must be larger than or equal to the first element. |
Data Types: single
| double
Output Arguments
J
— Jittered RGB image
numeric array
Jittered RGB image, returned as a numeric array of the same size and data type as
the input image, I
.
Data Types: single
| double
| uint8
| uint16
More About
HSV Color Space
The HSV color space defines the hue, saturation, and value (brightness) for each pixel, respectively, as described in the table.
Attribute | Description |
---|---|
Hue | Value from 0 to 1 that corresponds to
the color’s position on a color wheel. As hue increases from 0
to 1 , the color transitions from red to orange, yellow, green,
cyan, blue, magenta, and finally back to red. |
Saturation | Amount of hue or departure from neutral. 0 indicates a
grayscale image and 1 indicates maximum saturation. |
Value | Maximum value among the red, green, and blue components of a specific color. |
Version History
Introduced in R2019b
See Also
rgb2hsv
| hsv2rgb
| randomAffine2d
| randomWindow2d
| centerCropWindow2d
| jitterIntensity
(Medical Imaging Toolbox)
