SIWFilter
Description
Use the SIWFilter
object to create a bandpass filter in
microstrip form. The filter is a combination of a Substrate Integrated Waveguide (SIW)
transmission line and split ring resonator.
Creation
Description
filter = SIWFilter
creates a default SIW filter with passband
of filter centered around 7 GHz, with a bandwidth of 1.5 GHz. Default substrate is
Teflon with a thickness of 0.253e-3 m.
filter = SIWFilter(
sets Properties using one or more
name-value arguments. For example, Name=Value
)SIWFilter(NumResonators=5)
creates
a filter with five resonators. Properties not specified retain their default
values.
Properties
Object Functions
charge | Calculate and plot charge distribution |
current | Calculate and plot current distribution |
dgs | Create defected ground structure of PCB element |
feedCurrent | Calculate current at feed port |
layout | Plot all metal layers and board shape |
mesh | Change and view mesh properties of metal or dielectric in PCB component |
shapes | Extract all metal layer shapes of PCB component |
show | Display PCB component structure or PCB shape |
sparameters | Calculate S-parameters for RF PCB objects |
Examples
Version History
Introduced in R2023b
