# estimateCustomObjectivePortfolio

Estimate optimal portfolio for user-defined objective function for `Portfolio` object

## Syntax

``[pwgt,pbuy,psell,exitflag] = estimateCustomObjectivePortfolio(obj,fun)``
``````[pwgt,pbuy,psell,exitflag] = estimateCustomObjectivePortfolio(___,Name=Value)``````

## Description

example

````[pwgt,pbuy,psell,exitflag] = estimateCustomObjectivePortfolio(obj,fun)` estimates optimal portfolio with a user-defined objective function for a `Portfolio` object. For details on using `estimateCustomObjectivePortfolio`, see Solver Guidelines for Custom Objective Problems Using Portfolio Objects.```

example

``````[pwgt,pbuy,psell,exitflag] = estimateCustomObjectivePortfolio(___,Name=Value)``` adds optional name-value arguments. ```

## Examples

collapse all

This example shows how to use `estimateCustomObjectivePortfolio` to solve a portfolio problem with a custom objective. You define the constraints for portfolio problems using functions for the `Portfolio` object and then you specify the objective function as an input to `estimateCustomObjectivePortfolio`. The objective function must be continuous (and preferably smooth).

Create `Portfolio` Object

Find the portfolio that solves the problem:

`$\begin{array}{l}\underset{\mathit{x}}{\mathrm{min}}\text{\hspace{0.17em}\hspace{0.17em}}{\mathit{x}}^{\mathit{T}}\mathit{x}\\ \mathit{s}.\mathit{t}.\text{\hspace{0.17em}}\sum _{\mathit{i}}{\mathit{x}}_{\mathit{i}}=1\\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}\mathit{x}\ge 0\end{array}$`

Create a `Portfolio` object and set the default constraints using `setDefaultConstraints`. In this case, the portfolio problem does not involve the mean or covariance of the assets returns. Therefore, you do not need to define the assets moments to create the `Portfolio` object. You need only to define the number of assets in the problem.

```% Create a Portfolio object p = Portfolio(NumAssets=6); % Define the constraints of the portfolio methods p = setDefaultConstraints(p); % Long-only, fully invested weights```

Define Objective Function

Define a function handle for the objective function ${\mathit{x}}^{\mathit{T}}\mathit{x}$.

```% Define the objective function objFun = @(x) x'*x;```

Solve Portfolio Problem

`Use` `estimateCustomObjectivePortfolio` to compute the solution to the problem.

```% Solve portfolio problem wMin = estimateCustomObjectivePortfolio(p,objFun)```
```wMin = 6×1 0.1667 0.1667 0.1667 0.1667 0.1667 0.1667 ```

The `estimateCustomObjectivePortfolio` function automatically assumes that the objective sense is to minimize. You can change that default behavior by using the `estimateCustomObjectivePortfolio` name-value argument `ObjectiveSense`=`'maximize'`.

This example shows how to use `estimateCustomObjectivePortfolio` to solve a portfolio problem with a custom objective and a return constraint. You define the constraints for portfolio problems, other than the return constraint, using functions for the `Portfolio` object and then you specify the objective function as an input to `estimateCustomObjectivePortfolio`. The objective function must be continuous (and preferably smooth). To specify a return constraint, you use the `TargetReturn` name-value argument.

Create `Portfolio` Object

Find the portfolio that solves the problem:

`$\begin{array}{l}\underset{\mathit{x}}{\mathrm{min}}\text{\hspace{0.17em}\hspace{0.17em}}{\mathit{x}}^{\mathit{T}}\mathit{x}\\ \mathit{s}.\mathit{t}.\text{\hspace{0.17em}}\sum _{\mathit{i}}{\mathit{x}}_{\mathit{i}}=1\\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}\mathit{x}\ge 0\end{array}$`

Create a `Portfolio` object and set the default constraints using `setDefaultConstraints`.

```% Create a Portfolio object load('SixStocks.mat') p = Portfolio(AssetMean=AssetMean,AssetCovar=AssetCovar); % Define the constraints of the portfolio methods p = setDefaultConstraints(p); % Long-only, fully invested weights```

Define Objective Function

Define a function handle for the objective function ${\mathit{x}}^{\mathit{T}}\mathit{x}$.

```% Define the objective function objFun = @(x) x'*x;```

When using the `Portfolio` object, you can use `estimateFrontierByReturn` to add a return constraint to the portfolio. However, when using the `estimateCustomObjectivePortfolio` function with a `Portfolio` object, you must add return constraints by using the `TargetReturn` name-value argument with a return target value.

The `Portfolio` object supports two types of return constraints: gross return and net return. The type of return constraint that is added to the portfolio problem is implicitly defined by whether you provide buy or sell costs to the `Portfolio` object using `setCosts`. If no buy or sell costs are present, the added return constraint is a gross return constraint. Otherwise, a net return constraint is added.

Gross Return Constraint

The gross portfolio return constraint for a portfolio is

`${\mathit{r}}_{0}+{\left(\mu -{\mathit{r}}_{0}\right)}^{\mathit{T}}\mathit{x}\ge {\mu }_{0},$`

where ${\mathit{r}}_{0}$ is the risk-free rate (with 0 as default), $\mu$ is the mean of assets returns, and ${\mu }_{0}$ is the target return.

Since buy or sell costs are not needed to add a gross return constraint, the `Portfolio` object does not need to be modified before using `estimateCustomObjectivePortfolio`.

```% Set a return target ret0 = 0.03; % Solve portfolio problem with a gross return constraint wGross = estimateCustomObjectivePortfolio(p,objFun, ... TargetReturn=ret0)```
```wGross = 6×1 0.1377 0.1106 0.1691 0.1829 0.1179 0.2818 ```

The return constraint is not added to the `Portfolio` object. In other words, the `Portfolio` properties are not modified by adding a gross return constraint in `estimateCustomObjectivePortfolio`.

Net Return Constraint

The net portfolio return constraint for a portfolio is

`${\mathit{r}}_{0}+{\left(\mu -{\mathit{r}}_{0}\right)}^{\mathit{T}}\mathit{x}-{\mathit{c}}_{\mathit{B}}^{\mathit{T}}\text{\hspace{0.17em}}\mathrm{max}\left\{0,\mathit{x}-{\mathit{x}}_{0}\right\}-{\mathit{c}}_{\mathit{S}}^{\mathit{T}}\text{\hspace{0.17em}}\mathrm{max}\left\{0,{\mathit{x}}_{0}-\mathit{x}\right\}\ge {\mu }_{0},$`

where ${\mathit{r}}_{0}$ is the risk-free rate (with 0 as default), $\mu$ is the mean of assets returns, ${\mathit{c}}_{\mathit{B}}$ is the proportional buy cost, ${\mathit{c}}_{\mathit{S}}$ is the proportional sell cost, ${\mathit{x}}_{0}$ is the initial portfolio, and ${\mu }_{0}$ is the target return.

To add net return constraints to the portfolio problem, you must use `setCosts` with the `Portfolio` object. If the `Portfolio` object has either of these costs, `estimateCustomObjectivePortfolio` automatically assumes that any added return constraint is a net return constraint.

```% Add buy and sell costs to the Portfolio object buyCost = 0.002; sellCost = 0.001; initPort = zeros(p.NumAssets,1); p = setCosts(p,buyCost,sellCost,initPort); % Solve portfolio problem with a net return constraint % wNet = estimateCustomObjectivePortfolio(p,objFun, ... % TargetReturn=ret0)```

As with the gross return constraint, the net return constraint is not added to the `Portfolio` object properties, however the `Portfolio` object is modified by the addition of buy or sell costs. Adding buy or sell costs to the `Portfolio` object does not affect any constraints besides the return constraint, but these costs do affect the solution of maximum return problems because the solution is the maximum net return instead of the maximum gross return.

This example shows how to use `estimateCustomObjectivePortfolio` to solve a portfolio problem with a custom objective and cardinality constraints. You define the constraints for portfolio problems using functions for the `Portfolio` object and then you specify the objective function as an input to `estimateCustomObjectivePortfolio`. For problems with cardinality constraints or continuous bounds, the objective function must be continuous and convex.

Create `Portfolio` Object

Find a long-only, fully weighted portfolio with half the assets that minimizes the tracking error to the equally weighted portfolio. Furthermore, if an asset is present in the portfolio, at least 10% should be invested in that asset. The porfolio problem is as follows:

`$\begin{array}{l}\underset{\mathit{x}}{\mathrm{min}}\text{\hspace{0.17em}\hspace{0.17em}}{\left(\mathit{x}-{\mathit{x}}_{0}\right)}^{\mathit{T}}\Sigma \left(\mathit{x}-{\mathit{x}}_{0}\right)\\ \mathit{s}.\mathit{t}.\text{\hspace{0.17em}}\sum _{\mathit{i}}{\mathit{x}}_{\mathit{i}}=1,\\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}\sum _{\mathit{i}}\mathit{#}\left({\mathit{x}}_{\mathit{i}}\ne 0\right)=3,\\ \text{\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}\hspace{0.17em}}{\mathit{x}}_{\mathit{i}}\ge 0.1\text{\hspace{0.17em}}\mathrm{or}\text{\hspace{0.17em}}{\mathit{x}}_{\mathit{i}}=0\end{array}$`

Create a `Portfolio` object and set the assets moments.

```load('SixStocks.mat') p = Portfolio(AssetMean=AssetMean,AssetCovar=AssetCovar); nAssets = size(AssetMean,1);```

Define the `Portfolio` constraints.

```% Fully invested portfolio p = setBudget(p,1,1); % Cardinality constraint p = setMinMaxNumAssets(p,3,3); % Conditional bounds p = setBounds(p,0.1,[],BoundType="conditional");```

Define Objective Function

Define a function handle for the objective function.

```% Define the objective function EWP = 1/nAssets*ones(nAssets,1); trackingError = @(x) (x-EWP)'*p.AssetCovar*(x-EWP);```

Solve Portfolio Problem

`Use` `estimateCustomObjectivePortfolio` to compute the solution to the problem.

```% Solve portfolio problem wMinTE = estimateCustomObjectivePortfolio(p,trackingError)```
```wMinTE = 6×1 0.1795 0.3507 0 0.4698 0 0 ```

## Input Arguments

collapse all

Object for portfolio, specified using a `Portfolio` object. When using a `Portfolio` object in the custom objective workflow, you do not need to use the mean-variance framework to estimate the mean and covariance. However, the custom objective workflow does require that you specify portfolio constraints. The `Portfolio` object that you use with the `estimateCustomObjectivePortfolio` function supports only the following constraints:

Note

If no initial portfolio is specified in `obj.InitPort`, the initial portfolio is assumed to be `0` so that `pbuy` = ```max(0, pwgt)``` and `psell` = `max(0, -pwgt)`. If no tracking portfolio is specified in `obj.TrackingPort`, the tracking portfolio is assumed to be `0`.

Data Types: `object`

Function handle that defines the objective function, specified using a function handle in terms of the portfolio weights.

Note

The objective function must be continuous and defined using only the portfolio weights as variables. If the portfolio problem has cardinality constraints and/or conditional bounds using `setMinMaxNumAssets` or `setBounds`, the objective function must also be convex. For more information, see Role of Convexity in Portfolio Problems.

Data Types: `function_handle`

### Name-Value Arguments

Specify optional pairs of arguments as `Name1=Value1,...,NameN=ValueN`, where `Name` is the argument name and `Value` is the corresponding value. Name-value arguments must appear after other arguments, but the order of the pairs does not matter.

Example: ```pwgt = estimateCustomObjectivePortfolio(p,fun,ObjectiveSense="maximize",TargetReturn=0.05)```

Sense of the optimization, specified as `ObjectiveSense` and a string or character vector with one of the following values:

• `"minimize"` — The solution minimizes the objective function.

• `"maximize"` — The solution maximizes the objective function.

Data Types: `string` | `char`

Target value for the portfolio return, specified as `TargetReturn` and a positive or negative scalar.

Note

In the `Portfolio` object, use `estimateFrontierByReturn` to add a return constraint to the portfolio. When you use `estimateCustomObjectivePortfolio`, return constraints are added by passing the name-value argument `TargetReturn` with the return target.

Data Types: `double`

## Output Arguments

collapse all

Optimal weight allocation of the portfolio problem, returned as a `NumAssets`-by-`1` vector.

Purchases relative to initial portfolio to achieve the optimal weight allocation of the portfolio problem, returned as a `NumAssets`-by-`1` vector.

Sales relative to initial portfolio to achieve the optimal weight allocation of the portfolio problem, returned as a `NumAssets` vector.

Reason the solver stopped, returned as an enumeration variable or integer. There are two types of `exitflag` output. If the problem is continuous, the `exitflag` output is an enumeration variable. If the problem is mixed-integer, then the `exitflag` output is an integer.

 Cornuejols, G. and Reha Tütüncü. Optimization Methods in Finance. Cambridge University Press, 2007.
