afterAll

Run function after all functions finish running in the background

collapse all in page

    Syntax

    B = afterAll(A,fcn,n)
    B = afterAll(A,fcn,n,PassFuture=true)

    Description

    example

    B = afterAll(A,fcn,n) returns a Future object B and runs the function fcn automatically after all elements in the Future array A finish.

    MATLAB® runs the function fcn using the concatenated outputs from each element in A. The outputs Y1,...,Ym from each Future object are concatenated vertically, in linear index order. For example, if A is a two-element Future vector with outputs y1 and y2 from the first and second Future objects respectively, MATLAB runs fcn([y1; y2]) after all elements in A finish.

    If the Future array A has M elements, MATLAB runs the function only once. When the scheduled function fcn finishes, the Future object B finishes.

    You create a Future object when:

    • You run a function in the background using backgroundPool.

    • You run a function on a parallel pool when you have Parallel Computing Toolbox™.

    For more information about using afterAll in parallel, see Use afterEach and afterAll to Run Callback Functions (Parallel Computing Toolbox).

    If any of the elements in A encounters an error, the Error property of B is an MException.

    B = afterAll(A,fcn,n,PassFuture=true) runs fcn(A) instead of using the concatenated outputs of each element in A.

    The Error property of B is an empty MException array, even if one or more elements in A encounter an error.

    Examples

    collapse all

    Open Live Script

    This example shows how to use afterEach to update a wait bar with the progress of functions running in the background.

    Create a wait bar, w.

    w = waitbar(0,'Please wait ...');

    Set the number of iterations for your for-loop, N. Store the current number of completed iterations, 0, and the total number of iterations, N, in the UserData property of the wait bar.

    N = 20;
w.UserData = [0 N];

    Run a for-loop with N iterations. In each iteration, use parfeval and backgroundPool to run pause in the background for a random number of seconds. Store each Future object in an array.

    for i = 1:N
    delay = rand;
    f(i) = parfeval(backgroundPool,@pause,0,delay);
end

    Use the helper function updateWaitbar to update the waitbar after each Future finishes.

    afterEach(f,@(~)updateWaitbar(w),0);

    Use delete to close the wait bar after all the Future objects finish.

    afterAll(f,@(~)delete(w),0);

    Define Helper Function

    Define the helper function updateWaitbar. The function increments the first element of the UserData property, then uses the vector to calculate the progress.

    function updateWaitbar(w)
    % Update a waitbar using the UserData property.

    % Check if the waitbar is a reference to a deleted object
    if isvalid(w)
        % Increment the number of completed iterations
        w.UserData(1) = w.UserData(1) + 1;

        % Calculate the progress
        progress = w.UserData(1) / w.UserData(2);

        % Update the waitbar
        waitbar(progress,w);
    end
end

    Input Arguments

    collapse all

    Input Future object, specified as a parallel.Future scalar or array.

    MATLAB runs the function fcn after each element in A finishes. If any of the elements in A encounters an error and you specify PassFuture as true, afterAll still runs fcn using that element.

    • If you specify PassFuture as true, the function is run as fcn(Aj) using each Future element Aj in A. If any of the elements in A encounters an error, afterAll does not finish with an error.

    • Otherwise, the function is run as fcn(X1,...,Xm) using the outputs X1,...,Xm from each Future element in A. If any of the elements in A encounters an error, afterAll finishes with an error.

    If the Future array has M elements, MATLAB runs the function M times. When the scheduled function fcn finishes, the Future object B finishes.

    Example: A = parfeval(backgroundPool,@magic,1,3);

    Callback function to run, specified as a function handle.

    Example: fcn = @magic

    Number of output arguments, specified as a nonnegative integer scalar.

    • If you specify PassFuture as true, n is the number of output arguments expected from running fcn(A) using the Future array A.

    • Otherwise, n is the number of output arguments expected from running fcn(Y1,...,Ym) using the vertically concatenated outputs Y1,...,Ym from each element Aj in the Future array A.

    Data Types: single | double | int8 | int16 | int32 | int64 | uint8 | uint16 | uint32 | uint64

    Output Arguments

    collapse all

    Output Future object, returned as a parallel.Future object.

    • Use fetchOutputs to retrieve results from B.

    • Use afterEach or afterAll to run a function when B completes.

    When you set PassFuture, you change the Error property of B:

    • If PassFuture is true, the Error property of B is an empty MException array, even if one or more elements in A encounter an error.

    • Otherwise, if any of the elements in A encounters an error, the Error property of B is an MException object.

      To find the cause of the error, use the cause property of B.Error.

    Version History

    Introduced in R2018a
