Use these blocks to specify the nonlinear behavior of amplifiers and mixers. Such behavior includes IP2/IP3, intermodulation distortion and 1-dB compression. You can also simulate frequency-dependent mismatches between components.
|Amplifier||Model amplifier in RF systems|
|Mixer||Model mixer in RF systems|
|IMT Mixer||Model mixer using intermodulation table (IMT)|
|Power Amplifier||Model power amplifier with memory|
|VGA||Model variable gain amplifier|
|OIP3 Testbench||Measure output third intercept point of system|
|IIP3 Testbench||Measure input third intercept point of system|
|OIP2 Testbench||Measure output second intercept point of system|
|IIP2 Testbench||Measure input second intercept point of system|
|IQ Demodulator||Convert RF signal to baseband signal|
|IQ Modulator||Convert baseband signal to RF signal|
|Modulator||Model RF to RF modulator|
|Demodulator||Model RF to RF demodulator|
- RF Noise and Nonlinearity Simulations
Simulate RF noise and nonlinearities.
- Carrier to Interference Performance of Weaver Receiver
A classic superheterodyne architecture filters images prior to frequency conversion.
- Measuring Image Rejection Ratio in Receivers
This example shows how to use the RF Blockset™ Circuit Envelope library to calculate the image rejection ratio (IRR) for high-side-injection in Weaver and Hartley receivers.
