Advisor.addExclusion

Add exclusions to model or exclusion file

Since R2021a

Syntax

Advisor.addExclusion(modelName,filterType,entityIdentifier)

Advisor.addExclusion(___,Name,Value)

Description

Advisor.addExclusion(modelName,filterType,entityIdentifier) adds an exclusion to an entity, like a block, subsystem, or Stateflow^® element, in the model modelName. The type of exclusion is specified by the filterType argument. The entity is specified by the entityIdentifier argument.

If you add an exclusion, you can save time during model development and verification because you limit the scope of the analysis that Model Advisor has to perform on your model.

Advisor.addExclusion(___,Name,Value) specifies options using one or more name-value arguments in addition to the input arguments in previous syntaxes. For example, you can use the checks argument to exclude an entity from specific Model Advisor checks or the rationale argument to provide a reason for the exclusion.

Examples

Exclude Simulink Block from Model Advisor Analysis

Use the Advisor.addExclusion function to exclude a Simulink^® block from Model Advisor analysis.

Open the slexAircraftExample model.

openExample('simulink_aerospace/AircraftLongitudinalFlightControlExample')

On the Simulink canvas, click the entity that you want to exclude from Model Advisor checks. For this example, click the Inport block named u.

Exclude the selected block from Model Advisor analysis by adding an exclusion to the block. In the MATLAB^® Command Window, enter:

Advisor.addExclusion('slexAircraftExample','Block',gcb);

'Block' specifies that the exclusion needs to filter out a Simulink block and the function gcb returns the path to the block that you selected. For more information, see gcb.

You can view the exclusion in the Model Advisor Exclusion Editor by right-clicking the Simulink canvas and selecting Model Advisor > Open Model Advisor Exclusion Editor.

The Model Advisor Exclusion Editor shows a table with a row for the u Inport block exclusion. The Filter Identifier column shows the pathname specified by the entityIdentifier argument and the Filter Type column shows the exclusion filter type specified by filterType argument. The Rationale and Check ID(s) columns are associated with the rationale and checks arguments.

Exclude Stateflow Chart from Model Advisor Analysis and Provide Rationale

Use the Advisor.addExclusion function to exclude a Stateflow chart from the Model Advisor analysis. This example requires Stateflow.

Open the sf_collatz model.

openExample('stateflow/StateTransitionActionsGetStartedExample')

In the Stateflow chart, click the entity that you want to exclude from Model Advisor checks. For this example, click the default transition {n = u;}.

Exclude the selected transition from Model Advisor analysis by adding an exclusion to the transition. In the MATLAB Command Window, enter:

Advisor.addExclusion('sf_collatz','Transition',gcb,'rationale','Do not analyze.')

You can view the exclusion in the Model Advisor Exclusion Editor by right-clicking the Simulink canvas and selecting Model Advisor > Open Model Advisor Exclusion Editor.

Input Arguments

modelName — Model to add exclusion to

character vector | string array

Model to add the exclusion to, specified as a character vector or string array.

Data Types: char | string

filterType — Type of entity to exclude

Block | BlockType | Subsystem | Library | MaskType | ...

Type of entity to exclude, specified as one of these values.

Value	Description
Block	Simulink block
BlockType	Blocks with a specific BlockType property value
Subsystem	Blocks inside a subsystem
Library	Instances of a library block
MaskType	Blocks or subsystems with a specific MaskType property value
Stateflow	Stateflow blocks in Simulink
Chart	Every entity inside Stateflow chart
State	Stateflow State
Transition	Stateflow Transition
Junction	Stateflow Junction
GraphicalFunction	Stateflow Graphical Function
MatlabFunction	Stateflow MATLAB Function
SimulinkFunction	Stateflow Simulink Function
TruthTable	Stateflow Truth Table
SimulinkBasedState	Simulink based state in Stateflow

Example: Advisor.addExclusion('mymodel', 'Block', 'mymodel/Constant')

Data Types: char | string

entityIdentifier — Identifier for entity that you want to exclude

BlockType value | MaskType value | pathname

Identifier for the entity that you want to exclude, specified as a BlockType property value, MaskType property value, or pathname.

The format of the entityIdentifier value depends on which filterType you specified.

filterType value	entityIdentifier value	Example
BlockType	Value of the BlockType property for the block	Use the function gcb to get the currently selected block and get_param to get the block type. myblock = gcb; blockType = get_param(myblock,'BlockType'); Advisor.addExclusion('mymodel','BlockType',blockType);
MaskType	Value of the MaskType property for the block	Use the function gcb to get the current block and get_param to get the mask type. blockWithMask = gcb; maskType = get_param(blockWithMask,'MaskType'); Advisor.addExclusion('mymodel','MaskType',maskType);
All other filterType values	Pathname for the entity	You can use the functions gcb or find_system to get the pathname for an entity. myblock = gcb; Advisor.addExclusion('mymodel','Block',myblock)

Example: Advisor.addExclusion('mymodel','BlockType',blockType)

Example: Advisor.addExclusion('mymodel','MaskType',maskType)

Example: Advisor.addExclusion('mymodel','Block','mymodel/Constant')

Data Types: char | string

Name-Value Arguments

Specify optional pairs of arguments as Name1=Value1,...,NameN=ValueN, where Name is the argument name and Value is the corresponding value. Name-value arguments must appear after other arguments, but the order of the pairs does not matter.

Before R2021a, use commas to separate each name and value, and enclose Name in quotes.

Example: Advisor.addExclusion('mymodel', 'BlockType', 'Integrator', 'checks', {'mathworks.jmaab.jc_0231', 'mathworks.jmaab.jc_0222'}, 'validateChecks', true);

checks — Checks that exclusion applies to

cell array of character vectors

Checks that the exclusion applies to, specified as a cell array of Model Advisor check IDs.

By default, when you add an exclusion to an entity, the exclusion applies to all checks. You can use the checks argument to exclude only the selected checks.

Example: Advisor.addExclusion('mymodel','Block','mymodel/Constant','checks',{'mathworks.design.UnconnectedLinesPorts'})

Example: Advisor.addExclusion('mymodel','Block','mymodel/Constant','checks',{'mathworks.jmaab.jc_0231','mathworks.design.UnconnectedLinesPorts'})

Data Types: cell

validateChecks — Validate that checks support exclusions

false (default) | true

Validate that the checks specified by the checks argument can be excluded, specified as a numeric or logical 0 (false) or 1 (true).

Certain checks, like Check usage of enumerated values, do not allow exclusions. If you specify validateChecks as true, Model Advisor warns that the check does not support exclusions.

Advisor.addExclusion('vdp','Block',gcb,...
'checks',{'mathworks.jmaab.jc_0231','mathworks.maab.na_0031'},..
'validateChecks',true);

The following checks do not support exclusions:
    {'mathworks.maab.na_0031'}

Example: Advisor.addExclusion('mymodel','Block','mymodel/Constant','checks',{'mathworks.jmaab.jc_0231','mathworks.maab.na_0031'},'validateChecks',true)

Data Types: logical

rationale — Reason for exclusion

character vector | string array

Reason for exclusion, specified as a character vector or string array.

Example: Advisor.addExclusion('mymodel','Block','mymodel/Constant','rationale','Block to be removed later.')

Data Types: char | string

Alternative Functionality

Model Advisor Exclusion Editor

You can also add exclusions from the Simulink canvas by using the Model Advisor Exclusion Editor. To add an exclusion from the Simulink canvas, right-click an entity, select Model Advisor, and select the menu option for the type of exclusion that you want to add. For more information, see Exclude Blocks from Model Advisor Check Analysis.

Version History

Introduced in R2021a

R2020a: Use pathname instead of Simulink Identifier (SID)

The function Simulink.ID.getSID is not recommended. Use the pathname instead of a Simulink Identifier (SID) when you specify the argument entityIdentifier. You can find the pathname by using the gcb or find_system functions.
