# qr

Orthogonal-triangular decomposition

## Syntax

```[Q,R] = qr(A) [Q,R] = qr(A,0) [Q,R,E] = qr(A) [Q,R,E] = qr(A,'matrix') [Q,R,e] = qr(A,'vector') [Q,R,e] = qr(A,0) X = qr(A) X = qr(A,0) R = qr(A) R = qr(A,0) [C,R] = qr(A,B) [C,R,E] = qr(A,B) [C,R,E] = qr(A,B,'matrix') [C,R,e] = qr(A,B,'vector') [C,R] = qr(A,B,0) [C,R,e] = qr(A,B,0) ```

## Description

`[Q,R] = qr(A)`, where `A` is `m`-by-`n`, produces an `m`-by-`n` upper triangular matrix `R` and an `m`-by-`m` unitary matrix `Q` so that `A = Q*R`.

`[Q,R] = qr(A,0)` produces the economy-size decomposition. If `m > n`, only the first `n` columns of `Q` and the first `n` rows of `R` are computed. If `m<=n`, this is the same as ```[Q,R] = qr(A)```.

If A is full:

`[Q,R,E] = qr(A)` or ```[Q,R,E] = qr(A,'matrix')``` produces unitary `Q`, upper triangular `R` and a permutation matrix `E` so that `A*E = Q*R`. The column permutation `E` is chosen so that `abs(diag(R))` is decreasing.

`[Q,R,e] = qr(A,'vector')` returns the permutation information as a vector instead of a matrix. That is, `e` is a row vector such that `A(:,e) = Q*R`.

`[Q,R,e] = qr(A,0)` produces an economy-size decomposition in which `e` is a permutation vector, so that `A(:,e) = Q*R`.

`X = qr(A)` and `X = qr(A,0)` return a matrix `X` such that `triu(X)` is the upper triangular factor `R`.

If A is sparse:

`R = qr(A)` computes a `Q`-less `QR` decomposition and returns the upper triangular factor `R`. Note that `R = chol(A'*A)`. Since `Q` is often nearly full, this is preferred to `[Q,R] = QR(A)`.

`R = qr(A,0)` produces economy-size `R`. If `m>n`, `R` has only `n` rows. If `m<=n`, this is the same as `R = qr(A)`.

`[Q,R,E] = qr(A)` or `[Q,R,E] = qr(A,'matrix')` produces unitary `Q`, upper triangular `R` and a permutation matrix `E` so that `A*E = Q*R`. The column permutation `E` is chosen to reduce fill-in in R.

`[Q,R,e] = qr(A,'vector')` returns the permutation information as a vector instead of a matrix. That is, `e` is a row vector such that `A(:,e) = Q*R`.

`[Q,R,e] = qr(A,0)` produces an economy-size decomposition in which `e` is a permutation vector, so that `A(:,e) = Q*R`.

`[C,R] = qr(A,B)`, where `B` has as many rows as `A`, returns `C = Q'*B`. The least-squares solution to `A*X = B` is ```X = R\C```.

`[C,R,E] = qr(A,B)` or ```[C,R,E] = qr(A,B,'matrix')```, also returns a fill-reducing ordering. The least-squares solution to `A*X = B` is ```X = E*(R\C)```.

`[C,R,e] = qr(A,B,'vector')` returns the permutation information as a vector instead of a matrix. That is, the least-squares solution to `A*X = B` is ```X(e,:) = R\C```.

`[C,R] = qr(A,B,0)` produces economy-size results. If `m>n`, `C` and `R` have only `n` rows. If `m<=n`, this is the same as `[C,R] = qr(A,B)`.

`[C,R,e] = qr(A,B,0)` additionally produces a fill-reducing permutation vector `e`. In this case, the least-squares solution to `A*X = B` is ```X(e,:) = R\C```.

## Examples

Find the least squares approximate solution to ```A*x = b``` with the `Q`-less `QR` decomposition and one step of iterative refinement:

```if issparse(A), R = qr(A); else R = triu(qr(A)); end x = R\(R'\(A'*b)); r = b - A*x; err = R\(R'\(A'*r)); x = x + err;```
