Cross-spectrogram using short-time Fourier transforms

`s = xspectrogram(x,y)`

`s = xspectrogram(x,y,window)`

`s = xspectrogram(x,y,window,noverlap)`

`s = xspectrogram(x,y,window,noverlap,nfft)`

```
[s,w,t]
= xspectrogram(___)
```

```
[s,f,t]
= xspectrogram(___,fs)
```

```
[s,w,t]
= xspectrogram(x,y,window,noverlap,w)
```

```
[s,f,t]
= xspectrogram(x,y,window,noverlap,f,fs)
```

`[___,c] = xspectrogram(___)`

`[___] = xspectrogram(___,freqrange)`

`[___] = xspectrogram(___,'MinThreshold',thresh)`

`[___] = xspectrogram(___,spectrumtype)`

`xspectrogram(___)`

`xspectrogram(___,freqloc)`

`[___] = xspectrogram(___,`

returns the cross-spectrogram over the frequency range specified by
`freqrange`

)`freqrange`

. Valid options for
`freqrange`

are `'onesided'`

,
`'twosided'`

, and `'centered'`

.

`[___] = xspectrogram(___,`

returns short-term cross power spectral density estimates if
`spectrumtype`

)`spectrumtype`

is specified as `'psd'`

and returns short-term cross power spectrum estimates if
`spectrumtype`

is specified as
`'power'`

.

`xspectrogram(___)`

with no output arguments
plots the cross-spectrogram in the current figure window.

`xspectrogram(___,`

specifies the axis on which to plot the frequency. Specify
`freqloc`

)`freqloc`

as either `'xaxis'`

or
`'yaxis'`

.

[1] Oppenheim, Alan V., Ronald W. Schafer, and John R. Buck. *Discrete-Time
Signal Processing*. 2nd Ed. Upper Saddle River, NJ: Prentice
Hall, 1999.

[2] Mitra, Sanjit K. *Digital Signal Processing:
A Computer-Based Approach*. 2nd Ed. New York: McGraw-Hill,
2001.

`cpsd`

| `mscohere`

| `spectrogram`
