Custom Geometry and PCB Fabrication
Create your own customized 2-D and 3-D antenna geometry or import a 2-D array mesh. Define the feed for this arbitrary element and analyze the antenna or array by using analysis functions. Create and combine geometric shapes for PCB antennas. Select PCB antenna connectors and manufacturing services. Write Gerber files for PCB antenna manufacturing.
You can also use PCB Antenna Designer app to design, analyze, and export single or multi-feed PCB antennas.
