rlSARSAAgent

SARSA reinforcement learning agent

Description

The SARSA algorithm is an on-policy reinforcement learning method for environments with a discrete action space. A SARSA agent trains a Q-value function critic to estimate the value of the current epsilon-greedy policy (it does not try to directly learn an optimal policy).

Note

SARSA agents do not support recurrent networks.

For more information on SARSA agents, see SARSA Agent.

For more information on the different types of reinforcement learning agents, see Reinforcement Learning Agents.

Creation

Syntax

agent = rlSARSAAgent(critic,agentOptions)

Description

agent = rlSARSAAgent(critic,agentOptions) creates a SARSA agent with the specified critic network and sets the AgentOptions property.

Input Arguments

critic — Critic

rlQValueFunction object

Critic, specified as an rlQValueFunction object. For more information on creating critics, see Create Policies and Value Functions.

Properties

AgentOptions — Agent options

rlSARSAAgentOptions object

Agent options, specified as an rlSARSAAgentOptions object.

UseExplorationPolicy — Option to use exploration policy for simulation and deployment

false (default) | true

Option to use exploration policy when selecting actions during simulation or after deployment, specified as a one of the following logical values.

• true — Use the base agent exploration policy when selecting actions in sim and generatePolicyFunction. Specifically, in this case the agent uses the rlEpsilonGreedyPolicy. Since the action selection has a random component, the agent explores its action and observation spaces.

• false — Force the agent to use the base agent greedy policy (the action with maximum likelihood) when selecting actions in sim and generatePolicyFunction. Specifically, in this case the agent uses the rlMaxQPolicy policy. Since the action selection is greedy the policy behaves deterministically and the agent does not explore its action and observation spaces.

Note

This option affects only simulation and deployment; it does not affect training. When you train an agent using train, the agent always uses its exploration policy independently of the value of this property.

ObservationInfo — Observation specifications

specification object | array of specification objects

Observation specifications, specified as an rlFiniteSetSpec or rlNumericSpec object or an array containing a mix of such objects. Each element in the array defines the properties of an environment observation channel, such as its dimensions, data type, and name.

If you create the agent by specifying an actor or critic, the value of ObservationInfo matches the value specified in the actor and critic objects. If you create a default agent, the agent constructor function sets the ObservationInfo property to the input argument observationInfo.

You can extract observationInfo from an existing environment, function approximator, or agent using getObservationInfo. You can also construct the specifications manually using rlFiniteSetSpec or rlNumericSpec.

Example: [rlNumericSpec([2 1]) rlFiniteSetSpec([3,5,7])]

ActionInfo — Action specification

rlFiniteSetSpec object

Action specifications, specified as an rlFiniteSetSpec object. This object defines the properties of the environment action channel, such as its dimensions, data type, and name.

Note

For this agent, only one action channel is allowed.

If you create the agent by specifying a critic object, the value of ActionInfo matches the value specified in critic. If you create a default agent, the agent constructor function sets the ActionInfo property to the input argument ActionInfo.

You can extract actionInfo from an existing environment, function approximator, or agent using getActionInfo. You can also construct the specification manually using rlFiniteSetSpec.

Example: rlFiniteSetSpec([3,-5,7])]

SampleTime — Sample time of agent

1 (default) | positive scalar | -1

Sample time of the agent, specified as a positive scalar or as -1.

Within a MATLAB^® environment, the agent is executed every time the environment advances, so, SampleTime does not affect the timing of the agent execution.

Within a Simulink^® environment, the RL Agent block that uses the agent object executes every SampleTime seconds of simulation time. If SampleTime is -1 the block inherits the sample time from its input signals. Set SampleTime to -1 when the block is a child of an event-driven subsystem.

Note

Set SampleTime to a positive scalar when the block is not a child of an event-driven subsystem. Doing so ensures that the block executes at appropriate intervals when input signal sample times change due to model variations.

Regardless of the type of environment, the time interval between consecutive elements in the output experience returned by sim or train is always SampleTime.

If SampleTime is -1, for Simulink environments, the time interval between consecutive elements in the returned output experience reflects the timing of the events that trigger the RL Agent block execution, while for MATLAB environments, this time interval is considered equal to 1.

This property is shared between the agent and the agent options object within the agent. Therefore, if you change it in the agent options object, it gets changed in the agent, and vice versa.

Example: SampleTime=-1

Object Functions

train	Train reinforcement learning agents within a specified environment
sim	Simulate trained reinforcement learning agents within specified environment
getAction	Obtain action from agent, actor, or policy object given environment observations
getActor	Extract actor from reinforcement learning agent
setActor	Set actor of reinforcement learning agent
getCritic	Extract critic from reinforcement learning agent
setCritic	Set critic of reinforcement learning agent
generatePolicyFunction	Generate MATLAB function that evaluates policy of an agent or policy object

Examples

Create a SARSA Agent

Create or load an environment interface. For this example load the Basic Grid World environment interface also used in the example Train Reinforcement Learning Agent in Basic Grid World.

env = rlPredefinedEnv("BasicGridWorld");

Get observation and action specifications.

obsInfo = getObservationInfo(env);
actInfo = getActionInfo(env);

A SARSA agent uses a parametrized Q-value function to estimate the value of the policy. A Q-value function takes the current observation and an action as inputs and returns a single scalar as output (the estimated discounted cumulative long-term reward for taking the action from the state corresponding to the current observation, and following the policy thereafter).

Since both observation and action spaces are discrete and low-dimensional, use a table to model the Q-value function within the critic. rlTable creates a value table object from the observation and action specifications objects.

Create a table approximation model derived from the environment observation and action specifications.

qTable = rlTable(obsInfo,actInfo);

Create the Q-value function approximator object using qTable and the environment specification objects. For more information, see rlQValueFunction.

critic = rlQValueFunction(qTable,obsInfo,actInfo);

Create a SARSA agent using the approximator object.

agent = rlSARSAAgent(critic)

agent =
  rlSARSAAgent with properties:

            AgentOptions: [1x1 rl.option.rlSARSAAgentOptions]
    UseExplorationPolicy: 0
         ObservationInfo: [1x1 rl.util.rlFiniteSetSpec]
              ActionInfo: [1x1 rl.util.rlFiniteSetSpec]
              SampleTime: 1

Specify an Epsilon value of 0.05.

opt = rlSARSAAgentOptions;
agent.AgentOptions.EpsilonGreedyExploration.Epsilon = 0.05;

To check your agent, use getAction to return the action from a random observation.

act = getAction(agent,{randi(numel(obsInfo.Elements))});
act{1}

ans =
1

You can now test and train the agent against the environment.

Version History

Introduced in R2019a
