Run Multiple Simulations

Provide collection of inputs to model and run multiple simulations with these inputs using the parsim function, the batchsim function, or the Multiple Simulations panel in Simulink®

For workflows that involve multiple parallel simulations and logging of large data, you can use the parsim or batchsim function, or run the simulations with the Multiple Simulations panel in the Simulink Editor.

With a Parallel Computing Toolbox™ license, you can use the parsim function to run the simulations in parallel. The function distributes multiple simulations to parallel workers to speed up overall simulation time. Using the parsim function with Parallel Computing Toolbox allows you to automate the creation of parallel pools, identifies file dependencies, and manages build artifacts for accelerator and rapid accelerator simulations. The parsim function runs simulations in serial if a Parallel Computing Toolbox license is not available.

You can use the batchsim function with Parallel Computing Toolbox and MATLAB® Parallel Server™ licenses. When you use the batchsim function, simulations are offloaded onto a compute cluster. You can open a separate MATLAB session to access the job and the results.

To get started, see Running Multiple Simulations and Run Parallel Simulations for a Thermal Model of a House Using parsim.

Fonctions

batchsimOffload simulations to run on a compute cluster
parsimSimulate dynamic system multiple times in parallel or serial
applyToModelApply configuration specified on Simulink.SimulationOutput object to model
setBlockParameterSet block parameter values on Simulink.SimulationInput object
setModelParameterSpecify parameter values for simulation configured using Simulink.SimulationInput object
setInitialStateConfigure Simulink.SimulationInput object to set initial state for simulation
setExternalInputSet external inputs for simulation on SimulationInput object
setVariableSet variable value on SimulationInput object
validateValidate contents of SimulationInput object
setPreSimFcnSpecify MATLAB function to run before start of each simulation on Simulink.SimulationInput object
setPostSimFcn Set MATLAB function to run after each simulation
loadVariablesFromMATFileLoad variables from MAT file into Simulink.SimulationInput object
loadVariablesFromExternalSourceLoad variables from a custom file into Simulink.SimulationInput object
getSimulationJobsGet all Simulink.Simulation.Job objects from cluster
showContentsView contents of Simulink.SimulationInput object

Classes

Simulink.SimulationInputCreates SimulationInput objects to make changes to model for multiple or individual simulations
Simulink.Simulation.VariableVariables in Simulink.SimulationInput objects
Simulink.Simulation.BlockParameterBlock parameters in Simulink.SimulationInput objects
Simulink.Simulation.Future Create Future object for simulation
Simulink.Simulation.Job Execute batchsim to create a Simulink.Simulation.Job object, simJob

Outils

Multiple SimulationsRun multiple simulations from the Simulink Editor
Simulation ManagerMonitor multiple simulations and visualize the simulation data
