# verifyNetworkRobustness

## Syntax

## Description

verifies whether the network `result`

= verifyNetworkRobustness(`net`

,`XLower`

,`XUpper`

,`label`

)`net`

is adversarially robust with respect to
the class `label`

when the input is between `XLower`

and
`XUpper`

. For more information, see Adversarial Examples.

A network is robust to adversarial examples for a specific input if the predicted class
does not change when the input is perturbed between `XLower`

and
`XUpper`

. For more information, see Algorithms.

The `verifyNetworkRobustness`

function requires the Deep Learning Toolbox Verification Library support package. If this support package is not installed, use the
**Add-On Explorer**. To open the **Add-On Explorer**, go
to the MATLAB^{®} Toolstrip and click **Add-Ons** > **Get Add-Ons**.

also specifies the mini-batch size.`result`

= verifyNetworkRobustness(___,MiniBatchSize=`miniBatchSize`

)* (since R2023b)*

## Examples

## Input Arguments

## Output Arguments

## More About

## Algorithms

To verify the robustness of a network for an input, the function checks that when the input is perturbed between the specified lower and upper bound, the output does not significantly change.

Let *X* be an input with respect to which you want to test the robustness
of the network. To use the `verifyNetworkRobustness`

function, you must
specify a lower and upper bound for the input. For example, let $$\u03f5$$ be a small perturbation. You can define a lower and upper bound for the input
as $${X}_{\text{lower}}=X-\u03f5$$ and $${X}_{\text{upper}}=X+\u03f5$$, respectively.

To verify the adversarial robustness of the network, the function checks that, for all
inputs between *X*_{lower} and
*X*_{upper}, no adversarial example exists. To check
for adversarial examples, the function uses these steps.

Create an input set using the lower and upper input bounds.

Pass the input set through the network and return an output set. To reduce computational overhead, the function performs abstract interpretation by approximating the output of each layer using the DeepPoly [2] method.

Check if the specified label remains the same for the entire input set. Because the algorithm uses overapproximation when it computes the output set, the result can be unproven if part of the output set corresponds to an adversarial example.

If you specify multiple pairs of input lower and upper bounds, then the function verifies the robustness for each pair of input bounds.

**Note**

Because of floating-point round-off error, the verification results might be slightly different when working with networks produced using C/C++ code generation.

## References

[1] Goodfellow, Ian J., Jonathon Shlens, and Christian Szegedy. “Explaining and Harnessing Adversarial Examples.” Preprint, submitted March 20, 2015. https://arxiv.org/abs/1412.6572.

[2] Singh, Gagandeep, Timon Gehr,
Markus Püschel, and Martin Vechev. “An Abstract Domain for Certifying Neural Networks”.
*Proceedings of the ACM on Programming Languages* 3, no. POPL (January 2,
2019): 1–30. https://dl.acm.org/doi/10.1145/3290354.

## Extended Capabilities

## Version History

**Introduced in R2022b**
